| Work area |
1325/1530/2030/2040/2060 (can be Customized) |
| Color |
White and Green (can be Customized) |
| Working Voltage |
380V/3PH/50Hz (option) |
| Table |
Vacuum table with 4 zones |
| Control System |
DSP A11 control |
| Spindle |
HQD 6kw air cooling spindle |
| Spindle Speed |
0-24000RPM |
| Inverter |
5.5 KW Fuling inverter |
| Drive Motors |
FL118 Motor and Leadshine 860H |
| Frame |
New Type Heavy Duty Body |
| Lubrication |
Manual Lubrication System |
| Gantry structure |
Steel Gantry |
| Option |
Automatic Oil Mist Cooling |
| X, Y Structure |
ABBA/PMI 20# Guide Rails |
| Z Structure |
TBI Ball Screw Ball Screw Transmission |
| Tool Sensor |
Semi-Automatic Tool Sensor |
| Limited Switch |
Japan Omron Limited Switch |
| Wire |
High Soft Shjeld with Copper Wire to Protect Against Static Electricity |
