| 66621100M,,.6090 Parameters |
| Model |
LXM1325 4axis cnc router |
| Driver and Inverter |
Japanese Yaskawa driver motors |
| X Y Z Traveling Area |
1300mm*2500mm*600mm |
| Table Structure |
Vacuum & T-Slot |
| Spindle Power |
9.0KW air Cooling |
| Transmission |
Z axis Taiwan TBI Ball Screw and XY axis gear transmission |
| Max. Spindle Speed |
24000r/min |
| Max. Traveling Speed |
15000mm/min |
| Max. Working Speed |
12000mm/min |
| Processing Accuracy |
±0.025mm |
| Reposition Accuracy |
≤0.025mm |
| Operation System |
Taiwan Syntec 6MB controller |
| Software |
Type3, Artcam, Ucancam |
| Working Voltage |
AC 220/380V |
| Net Weight/Gross Weight |
1650/1800KG |
| Reducer |
Japan SHIMPO |
| Rail |
Taiwan HIWIN square rails |
| Feature |
180 degree swing head |
